HBD 400 Dual Laser 2×500W – High-power SLM metal 3D printer
- Dual 500W fiber lasers provide a balance of productivity and precision.
- 350 × 400 × 400 mm build volume supports a wide range of industrial applications.
- LPBF technology delivers dense metal parts with excellent mechanical properties.
- Compatible with stainless steel, titanium alloys, aluminum alloys, and tool steels.
- Advanced monitoring systems ensure stable printing conditions and reliable results.
HBD 400 SLM Metal 3D PRINTER
Precision Redefined in Metal 3D Printing
WHY HBD 400?
High Productivity Configuration
Six precise 500W/1000W fibre lasers operate, intelligent variable speed design and bidirectional
re-coater completing the process in 3 seconds, coupled with a large building volume of
350mm×400mm×400mm, this results in an efficient solution for scaled production.
Long-lasting Filtration System
The filtration system utilizes next-generation PTFE-coated filter elements, meeting H13 standards with a capture efficiency of up to 99.9%, capable of trapping particles as small as 0.3μm. The filter includes self-cleaning features, providing a filter element lifetime of over 5 years. Optimized gas-flow configuration enables secure and efficient waste reclamation in inert gas environments, ensuring optimal printing conditions.
Precision Laser Calibration System
Seamless multi-beam laser stitching, the HBD 400 automatic laser calibration system enables an
automatic scanning strategy tailored to the process conditions, with a calibration accuracy up to
0.05 mm, enhancing process stability and part quality.
3D Print Cases
The production of charger plug terminal utilizing HBD 400 metal AM system achieves integrated forming of multiple
stacked parts with 6 synchronized lasers. The output reaches 19.2 pieces per hour, which is three times more efficient
than dual-laser systems. Rapid prototyping speeds up the development cycle without additional tooling costs, making
small batch production more cost-effective.
Hydraulic Manifold
Industry: 3C Electronics
Material: 316L
Size: 24×23×15mm
Weight: 4.8g
Quantity: 444
Time: 23h 54min
| Parameter | Specification |
|---|---|
| Build Volume | 350mm × 400mm × 400mm (height incl. build plate) |
| Laser Power | 4 Lasers, 500W / 1000W | 6 Lasers, 500W / 1000W | 8 Lasers, 1000W |
| Layer Thickness | 20μm – 120μm |
| Spot Diameter | 70μm – 80μm, 140μm – 160μm (Optional: Guangchi II) |
| Scanning Speed | ≤ 10m/s |
| Oxygen Content | ≤ 100ppm |
| Protective Atmosphere | Integral sealed system with automatic oxygen monitoring, recycling, cleaning and collection efficiency ≥ 99% |
| Relative Density | 99.9%+ |
| Typical Accuracy | 0.05 – 0.2mm |
| Metal Powder | Titanium alloys, Aluminum alloys, Superalloys, Stainless steel, Mould steel, etc. |
| Process Parameter Configuration | Tailored parameter set for specific applications, user-modifiable |
| Weight | Approx. 3300kg |
| External Dimensions | 1900mm × 1650mm × 2300mm |
| Power Supply |
500W: AC380V, 50/60Hz, peak power ≤14–16kW, average power ≤5.5–8.5kW 1000W: AC380V, 50/60Hz, peak power ≤15–19kW, average power ≤6.5–11.5kW |
