NCT DK7732F CNC Wire Cut EDM Machine
- CNC molybdenum Wire Cut EDM machine
- 630 × 500 mm X/Y travel for large industrial workpieces
- Maximum machining speed of 350 mm²/min
- Maximum workpiece weight capacity of 800 kg
- High-precision machining with surface roughness up to 0.6 μm
Precision Wire EDM Machining for Industrial Manufacturing
CNC Wire Cut EDM Machine for Precision Applications
The NCT DK7732F is a CNC Wire Cut EDM machine designed for precision industrial machining applications. Its optimized wire cutting system supports accurate machining performance and reliable industrial production workflows.
Stable Machine Structure for Industrial Operation
Built with a rigid machine frame and durable industrial components, the DK7732F delivers stable machining conditions, reduced vibration, and reliable long-term industrial performance.
Precision Wire Cutting Capability
The machine is engineered for accurate wire EDM machining and supports precise cutting operations for complex industrial components and demanding manufacturing applications.
Optimized Working Area for Industrial Components
The DK7732F features an optimized machining area designed to support efficient processing of industrial workpieces and stable EDM machining performance during continuous operation.
Advanced CNC Control System
Equipped with a modern CNC control system, the machine provides accurate axis control, efficient machining management, and optimized workflow performance for industrial EDM applications.
Reliable EDM Performance and Productivity
The optimized machine configuration and stable cutting technology improve machining efficiency, support reliable production workflows, and maintain consistent machining quality.
Designed for Continuous Industrial Manufacturing
Developed for modern manufacturing environments, the NCT DK7732F combines precision wire EDM technology, stable machine construction, and reliable machining capability to support continuous industrial production operations.
Technical Specifications
Working Area |
|
|---|---|
Axis Travel X, Y |
320 mm |
Axis Travel X, Y |
400 mm |
Axis travel Z |
500 mm |
Axis travel U,V |
240 x 240 mm |
Max. workpiece weight |
400 kg |
Wire Diameter Range |
0.15-0.20 mm |
Coolant System |
|
Tank Capacity |
100 L |
Molibden Wirecut Machines |
|
Table size |
415 ×635 mm |
Table travel |
320 × 400 mm |
Max. workpiece thickness |
500 mm |
Max. taper angle / plate thickness |
±30 / 100 ° / mm |
Max. maching speed |
150 mm²/min |
Max. working current |
6 A |
Roughness |
1.5 um |
Wire travelling speed |
150 m/min |
Load of table |
400 kg |
Working solution |
Clean working fluid |
Working reservoir capacity |
100 L |
Power supply |
3N-380V/50Hz |
Power consumption |
3 KVA |
Installation |
|
Required floor space x height |
1600 × 1270 × 1700 mm |
Net machine weight |
1700 kg |
Next-generation NCT CNC controllers
Next-generation NCT CNC controllers deliver precise and efficient control for CNC machining applications. Designed for flexibility, NCT controllers support conversational programming, CAM software integration, and traditional G-code programming. Advanced features also help monitor machine performance and optimize operation, ensuring consistently high precision, reliability, and productivity.
.png)
myNCT – Conversational programming for CNC machines
myNCT is a user-friendly conversational CNC programming software designed to simplify and speed up machining workflows. Its intuitive interface makes programming accessible for both beginners and experienced operators, allowing users to achieve professional results with minimal training.
Key features of myNCT CNC programming software:
-3+2-axis milling for fast and precise machining of complex geometries
-Free-form contour pocket machining with high flexibility for intricate shapes
-Simple milling cycles for quick programming of common machining operations
-Thread milling for accurate thread production across various materials
-Automated drilling cycles to improve efficiency and productivity
-Driven-tool milling capabilities for combined milling and turning operations
-Turning cycles for precise grooving, threading, and turning applications
3D Solid Model Graphics – Accuracy and efficiency in CNC controllers
3D solid model graphics in CNC controllers provide an advanced solution for real-time visualization and verification of machining processes. This technology helps operators:
-Detect CNC programming errors before machining
-Prevent potential collisions and machine damage
-Monitor the workpiece and machining progress with high accuracy
-Improve productivity, reduce material waste, and maintain consistently high manufacturing quality
Machine Construction and Key Features
-Rigid cast iron bed, column, and slides for maximum stability
-Semi or fully enclosed splash guard for improved operator safety
-Precision linear guideways with ball or roller type bearings on all axes
-Central oil-lubricated slide system with telescopic metal guideway covers
-Belt-driven spindle designed for reliable high-speed machining
-40 spindle taper compatible with DIN or BT tooling systems
-Digital oil cooler for headstock thermal stabilization
-Compressed air spindle protection and automatic taper cleaning
-High-precision ground double nut ball screws
-Pretensioned ball screws supported on both ends for rigidity
- Three colour status lamp
-Drum type tool magazine with arm type ATC system
-Fast and reliable automatic tool changing process
-Designed for efficient production workflows
-Stable tool handling during high-speed machining operations
-NCT 304 Smart Touch CNC with intuitive touchscreen interface
-EnDat 2.2 absolute measuring system for precise positioning
-0.00005 mm positioning resolution with nano interpolation
-Advanced CNC control optimized for industrial machining applications
-Smooth and accurate axis movement under demanding workloads
-Optimized mechanical structure for long-term positioning accuracy
-Spindle bearing protection by compressed air
