MA-1720 Conventional Lathe
- Massive box-type bed for stable machining performance
- Hardened and precision-ground bedways for durability
- Gearbox-driven spindle system with reliable torque delivery
- Supports metric, inch, module, and DP threading operations
- Oil-bath lubrication system for smooth industrial operation
Industrial Conventional Turning for Precision Metalworking
Conventional Industrial Lathe Machine
The MA-1720 is a conventional lathe designed for industrial turning applications requiring stable machining performance, reliable operation, and versatile threading capability.
Massive Box-Type Bed Construction
The machine features a massive box-type bed with extra-wide guideways designed to improve rigidity, vibration absorption, and machining stability during industrial turning operations.
Hardened and Precision-Ground Bedways
The hardened and precision-ground bedways provide excellent wear resistance, long-term durability, and reliable machining accuracy for continuous industrial use.
Gearbox-Driven Spindle System
The rigid headstock integrates a full gear transmission spindle system engineered for stable torque delivery and dependable cutting performance across demanding machining applications.
Wide Threading and Feed Capability
The MA-1720 supports metric, inch, module, and DP threading with a wide range of feeds and threading configurations for versatile industrial metalworking operations.
Oil-Bath Lubrication System
The gearbox and apron system utilize oil-bath lubrication combined with continuous lubrication capability to support smooth operation and long-term industrial reliability.
Reliable Industrial Machining Performance
Designed for industrial workshop environments, the MA-1720 combines stable machine construction, reliable spindle performance, and versatile turning capability for precision machining applications.
.png)
Technical Specifications
Capacity |
|
|---|---|
Width of bed |
300 mm |
Distance between centers |
550 mm |
Compound rest travel |
250 mm |
Compound rest travel |
120 mm |
Swing over bed |
460 mm |
Swing over cross slide (option) |
285 mm |
Swing in gap |
630 (opt) mm |
Center height |
230 mm |
Headstock |
|
Number of spindle speeds |
12 steps |
Spindle bore |
58 mm |
Type of spindle nose |
A1-6 |
Speed range |
20 - 2000 rpm |
Thread & Feed |
|
Lead screw |
6 mm / 4 TPI |
Range of metric threads |
0,5 - 7 (24) mm |
Range of inch threads |
4 - 56 (36) TPI |
Range of Module threads |
0,25 - 3,5 (28) M |
Range of DP threads |
8 - 112 (36) TPI |
Range of longitudinal feeds |
0,05 - 0,88 mm/rev |
Range of cross feeds |
0,02 - 0,44 mm/rev |
Tailstock |
|
Size of internal taper |
MT4 |
Quill diameter |
58 mm |
Total travel of tailstock quill |
150 mm |
Motors |
|
Spindle drive motor |
3.8 kW |
Dimension and Weight |
|
Floor space x height |
1825 x 830 x 1237 mm |
Net weight (kg) |
1550 kg |
