NCT VD-510neo – High-Speed CNC Vertical Machining Center
- High-speed CNC vertical machining center designed for precision industrial production
- Rigid cast iron structure ensures excellent machining stability and vibration absorption
- 10,000 RPM spindle with BT40 tooling for accurate machining performance
- Fast automatic tool changer with 24-tool magazine improves production efficiency
- Advanced NCT Smart Touch CNC controller with touchscreen operation and CAM compatibility
Precision CNC Milling for Industrial Applications
High-Speed CNC Tapping Center
The NCT VD-510neo is a compact high-speed CNC tapping center designed for precision machining and efficient industrial production. Its rigid cast iron structure, BT30 spindle system, and advanced CNC technology ensure high-speed performance and excellent machining accuracy.
Rigid Cast Iron Construction for Maximum Stability
Built with a rigid cast iron bed, column, and slides, the VD-510neo provides excellent vibration absorption and machining stability during high-speed machining operations. Precision linear guideways and centralized lubrication systems ensure smooth axis movement and reliable long-term accuracy.
High-Speed Direct Drive Spindle Technology
Equipped with a direct-drive BT30 spindle system with 12,000 RPM standard speed and optional 20,000 RPM configuration, the VD-510neo supports highly accurate machining of small and complex components. Advanced spindle air cleaning and thermal stabilization systems maintain stable cutting performance and spindle reliability.
Ultra-Fast Automatic Tool Changing System
The machine includes a 21-position servo-driven tool magazine designed for extremely fast tool changes. Tool change times as low as 1.6 seconds improve machining productivity and reduce downtime in continuous production environments.
Advanced NCT Smart Touch CNC Controller
The VD-510neo features the NCT 304 Smart Touch CNC controller with touchscreen operation, graphical programming support, and advanced machining functions. The intelligent CNC system improves process control, positioning precision, and workflow efficiency for industrial machining applications.
Industrial-Grade Protection and Maintenance Systems
The machine is equipped with telescopic guideway covers, spindle taper air cleaning, lifetime grease-lubricated spindle bearings, and centralized oil lubrication systems to ensure reliable operation and reduced maintenance requirements.
Designed for High-Speed Industrial Production
The VD-510neo offers rapid traverse speeds up to 48 m/min on all axes, compact installation dimensions, and an optimized machine layout for efficient industrial production. Its fully enclosed splash guard option and ergonomic machine design improve safety and operator accessibility.
.png)
Technical Specifications
Working Area |
|
|---|---|
Table size X |
650 mm |
Table size Y |
400 mm |
T-slot number size distance |
14×3×125 mm |
Table load capacity |
250 kg |
Spindle nose distance from table surface / table center |
170 - 435 mm |
Spindle centre distance from column |
460 mm |
Positioning accuracy |
< 0,005 mm |
Repeatability accuracy |
< 0,003 mm |
Axis |
|
Number of Axis |
3 |
Number and type of X / Y / Z guideways |
Linear 2 / 2 / 2 |
X travel |
510 mm |
Y travel |
406 mm |
Z travel |
330 mm |
Rapid travel speed max. of Y / Z axis |
48 / 48 / 48 m/min |
Max. feed rate |
48 m/min |
Spindle |
|
Max. speed (standard) |
12000 RPM |
Max. speed (option.) |
20000 RPM |
Spindle taper size (standard) |
#30 |
Tooling |
BT 30 |
Spindle Motor |
|
Max. Power (standard) |
5.5 kW |
Max. torque (standard) |
18 Nm |
Tool Magazine |
|
Number of tool positions |
21 |
Max. tool length |
200 mm |
Max. tool diameter |
80 mm |
Max. tool weight |
3 kg |
Tool change time (T to T) |
1.6 sec |
Tool change time (C to C) |
2.5 sec |
Tool change time 180° |
2.8 sec |
Installation |
|
Floor space height |
1600 × 2150 × 2320 mm |
Net machine weight |
2600 kg |
Electrical connection |
3 × 400 V AC VA |
Air connection |
6 kg/cm2 |
Next-generation NCT CNC controllers
Next-generation NCT CNC controllers deliver precise and efficient control for CNC machining applications. Designed for flexibility, NCT controllers support conversational programming, CAM software integration, and traditional G-code programming. Advanced features also help monitor machine performance and optimize operation, ensuring consistently high precision, reliability, and productivity.
.png)
myNCT – Conversational programming for CNC machines
myNCT is a user-friendly conversational CNC programming software designed to simplify and speed up machining workflows. Its intuitive interface makes programming accessible for both beginners and experienced operators, allowing users to achieve professional results with minimal training.
Key features of myNCT CNC programming software:
-3+2-axis milling for fast and precise machining of complex geometries
-Free-form contour pocket machining with high flexibility for intricate shapes
-Simple milling cycles for quick programming of common machining operations
-Thread milling for accurate thread production across various materials
-Automated drilling cycles to improve efficiency and productivity
-Driven-tool milling capabilities for combined milling and turning operations
-Turning cycles for precise grooving, threading, and turning applications
3D Solid Model Graphics – Accuracy and efficiency in CNC controllers
3D solid model graphics in CNC controllers provide an advanced solution for real-time visualization and verification of machining processes. This technology helps operators:
-Detect CNC programming errors before machining
-Prevent potential collisions and machine damage
-Monitor the workpiece and machining progress with high accuracy
-Improve productivity, reduce material waste, and maintain consistently high manufacturing quality
Machine Construction and Key Features
-Rigid cast iron bed, column, and slides for maximum stability
-Semi or fully enclosed splash guard for improved operator safety
-Precision linear guideways with ball or roller type bearings on all axes
-Central oil-lubricated slide system with telescopic metal guideway covers
-Belt-driven spindle designed for reliable high-speed machining
-40 spindle taper compatible with DIN or BT tooling systems
-Digital oil cooler for headstock thermal stabilization
-Compressed air spindle protection and automatic taper cleaning
-High-precision ground double nut ball screws
-Pretensioned ball screws supported on both ends for rigidity
- Three colour status lamp
-Drum type tool magazine with arm type ATC system
-Fast and reliable automatic tool changing process
-Designed for efficient production workflows
-Stable tool handling during high-speed machining operations
-NCT 304 Smart Touch CNC with intuitive touchscreen interface
-EnDat 2.2 absolute measuring system for precise positioning
-0.00005 mm positioning resolution with nano interpolation
-Advanced CNC control optimized for industrial machining applications
-Smooth and accurate axis movement under demanding workloads
-Optimized mechanical structure for long-term positioning accuracy
-Spindle bearing protection by compressed air
